Amphenol Connector
| PRODUCT FAMILY |
|
Description: Mini SAS Connectors Pitch: 0.75mm Contacts No: 36, 72 and 144 Application: Networking,High-end Computing System,Server and Storage Systems
Type: Right Angle and Vertical SMT type |
| MATERIAL |
|
Contact Base Metal: Copper alloy Contact Area Finish: Gold over nickel Solder Area Finish: Tin over nickel Housing & Spacer: High temperature thermoplastic (UL 94V-0) Shorting Bar: Conductive pastic Lock Key: Copper alloy nickel |
| ELECTRICAL PERFORMANCE |
|
Current Rating: 0.5A max. per contact Voltage Rating: 30V AC/ DC max. Dielectric Withstanding Voltage: 300V DC Insulation Resistance: 1000mΩ min. Differential Impedance: 100Ω ± 10Ω
|
| MECHANICAL PERFORMANCE |
|
Durability: 250 mating cycles Mating Force: 50N max. Unmating Force: 10N max.
|
| Environmental |
|
Humidity: 24 cycles between 25˚C/ 80%RH Temperature Life: EIA-364-17, 105˚C for 336 hours Thermal Shock: -55˚C to 85˚C, 10 cycles |
| Product Environmental Compliance |
|
RoHS2.0: Compliant REACH SVHC: Yes |
